NIMOS 8 polyester shell pool
Ref. Provider TIERRA 8
NIMOS 8 polyester shell pool
Lazy shaped shell pool, 2 available dimensions,
8,50 x 3,93m or 9,50 x 4,30m,
Gently inclined floor, integrated stairs, coping, full filtration system, sealing parts
8,50 x 3,93m or 9,50 x 4,30m,
Gently inclined floor, integrated stairs, coping, full filtration system, sealing parts
Contemporary design and gradually sloped floor make the NIMOS pool the perfect choice for adults and children alike.
Delivered complete and ready to install, the Nemos is the choice of pool which can offer a large swimming area.
Resistant and easy to install, the NIMOS will stand the test of time.
Featuring integrated stairs and bench, the NIMOS offers unforgettable moments of relaxation.
The monobloc structure of the NIMOS coupled with the quality materials used for its manufacture guarantee perfect watertightness, flexibility and resistance.
Monobloc pool moulded from a polyester resin reinforced with glass fibres. A gel coat (a synthetic resin which gives a "gloss" finish) is then applied.
This type of pool proves to be highly resistant to an aggressive environment (UV, weather conditions, chemical water treatment ...).
![Nimos 8 polyester shell pool Nimos 8 polyester shell pool](/images/nimos-8.jpg)
![Nimos 9 polyester shell pool Nimos 9 polyester shell pool](/images/nimos-9.jpg)
![Nimos polyester shell pool filtration schema Nimos polyester shell pool filtration schema](/images/filtration-nimos-8.jpg)
Filtration schema for NIMOS
![Nimos polyester shell pool installation schema Nimos polyester shell pool installation schema](/images/installation-nimos-8.jpg)
NIMOS installation schema
![Dimensions Nimos 8 polyester shell pool Dimensions Nimos 8 polyester shell pool](/images/dimensions-nimos-8.jpg)
![Dimensions length Nimos 8 polyester shell pool right hand view Dimensions length Nimos 8 polyester shell pool right hand view](/images/dimensions-length-nimos-8-right.jpg)
![Dimensions Nimos 8 polyester shell pool Dimensions Nimos 8 polyester shell pool](/images/dimensions-length-nimos-8-left.jpg)
![Nimos 8 polyester shell pool above view dimensions Nimos 8 polyester shell pool above view dimensions](/images/dimensions-above-view-nimos-8.jpg)
![Width dimensions Nimos 9 polyester shell pool Width dimensions Nimos 9 polyester shell pool](/images/dimensions-width-nimos-9.jpg)
![Dimensions Nimos 9 polyester shell pool right hand view Dimensions Nimos 9 polyester shell pool right hand view](/images/dimensions-length-nimos-9-right.jpg)
![Dimensions Nimos 9 polyester shell pool left hand view Dimensions Nimos 9 polyester shell pool left hand view](/images/dimensions-nimos-9-left.jpg)
![Dimensions above view Nimos 9 polyester shell pool Dimensions above view Nimos 9 polyester shell pool](/images/dimensions-above-viewnimos-9.jpg)
The NIMOS pool shell range are supplied with a sand filtration system that includes :
![ESPA SILEN pump ESPA SILEN pump](/images/pump-espa-silen.jpg)
The SILEN impeller centrifugal pump is self-priming, compact and compatible with salt water treatments and has been designed for the filtration of residential pools.
Supplied with 50 mm union connections on the pump's inlet and outlet, a purge cap, large capacity pre-filter complete with a transparent lid featuring an anti-blocking system.
The SILEN also features internal thermal protection.
The body, floor and diffuser of the pump are made from polypropylene reinforced with glass fibre. Its rotor is made from Noryl® reinforced with glass fibres. Supports are made from polyamide reinforced by glass fibre. The motors axis is made from AISI 420. O-rings from NBR. Mechanical seals made from graphite-alumina. L-2521 aluminium motor body. Bobbin impregnated with epoxy varnish.
Dimensions of the pump
Dimensions ESPA SILEN 75 3/4HP model NIMOS 8
![Dimensions pump ESPA Silen 50 1/2HP Dimensions pump ESPA Silen 50 1/2HP](/images/dimensions-pump-espa.jpg)
Dimensions ESPA SILEN 100 1HP model NIMOS 9
![Dimensions ESPA SILEN 100 1HP Dimensions ESPA SILEN 100 1HP](/images/dimensions-espa-silen-100-pump.jpg)
Sand filter
![ASTRAL VESUBIO 450 sand filter ASTRAL VESUBIO 450 sand filter](/images/filter-astral-vesuvio.jpg)
![Spacer20 Spacer20](/images/spacer20.jpg)
Skimmer
Discharge nozzles
Main drain
Brush adaptor
Filter
Pump
Maintenance kit includes : Wall brush, telescopic handle, floating pipe, net, analysis pouch, manual vacuum.
- Coping
- Choice of colour (using RAL code)
- Thermal cover
- Pool floor projector
- Electrical box
- Salt water treatment
- pH regulation
Standard colour: blue. All other colours are available on option.
Delivered complete and ready to install, the Nemos is the choice of pool which can offer a large swimming area.
Resistant and easy to install, the NIMOS will stand the test of time.
Featuring integrated stairs and bench, the NIMOS offers unforgettable moments of relaxation.
The monobloc structure of the NIMOS coupled with the quality materials used for its manufacture guarantee perfect watertightness, flexibility and resistance.
Monobloc pool moulded from a polyester resin reinforced with glass fibres. A gel coat (a synthetic resin which gives a "gloss" finish) is then applied.
This type of pool proves to be highly resistant to an aggressive environment (UV, weather conditions, chemical water treatment ...).
![Nimos 8 polyester shell pool Nimos 8 polyester shell pool](/images/nimos-8.jpg)
![Nimos 9 polyester shell pool Nimos 9 polyester shell pool](/images/nimos-9.jpg)
![Nimos polyester shell pool filtration schema Nimos polyester shell pool filtration schema](/images/filtration-nimos-8.jpg)
Filtration schema for NIMOS
Model | NIMOS 8 | NIMOS 9 |
Dimensions | 8,50 x 3,93 | 9,50 x 4,30 |
Depth | 0,90 à 1,70 | 0,85 à 1,85 |
Standard colour | Blue | Blue |
Pump | 0,75HP | 1HP |
Diameter of filter | 500mm | 500mm |
![Nimos polyester shell pool installation schema Nimos polyester shell pool installation schema](/images/installation-nimos-8.jpg)
NIMOS installation schema
Designation
Sealing parts
1
Discharge nozzle
2
Brush adaptor
3
Main drain
4
Prevention drain
5
Projector (on option)
6
Skimmer
Dimensions
NIMOS 8
![Dimensions Nimos 8 polyester shell pool Dimensions Nimos 8 polyester shell pool](/images/dimensions-nimos-8.jpg)
![Dimensions length Nimos 8 polyester shell pool right hand view Dimensions length Nimos 8 polyester shell pool right hand view](/images/dimensions-length-nimos-8-right.jpg)
![Dimensions Nimos 8 polyester shell pool Dimensions Nimos 8 polyester shell pool](/images/dimensions-length-nimos-8-left.jpg)
![Nimos 8 polyester shell pool above view dimensions Nimos 8 polyester shell pool above view dimensions](/images/dimensions-above-view-nimos-8.jpg)
NIMOS 9
![Width dimensions Nimos 9 polyester shell pool Width dimensions Nimos 9 polyester shell pool](/images/dimensions-width-nimos-9.jpg)
![Dimensions Nimos 9 polyester shell pool right hand view Dimensions Nimos 9 polyester shell pool right hand view](/images/dimensions-length-nimos-9-right.jpg)
![Dimensions Nimos 9 polyester shell pool left hand view Dimensions Nimos 9 polyester shell pool left hand view](/images/dimensions-nimos-9-left.jpg)
![Dimensions above view Nimos 9 polyester shell pool Dimensions above view Nimos 9 polyester shell pool](/images/dimensions-above-viewnimos-9.jpg)
Filtration
The NIMOS pool shell range are supplied with a sand filtration system that includes :
- Pump ESPA SILEN
![ESPA SILEN pump ESPA SILEN pump](/images/pump-espa-silen.jpg)
Pump
The SILEN impeller centrifugal pump is self-priming, compact and compatible with salt water treatments and has been designed for the filtration of residential pools.
Supplied with 50 mm union connections on the pump's inlet and outlet, a purge cap, large capacity pre-filter complete with a transparent lid featuring an anti-blocking system.
The SILEN also features internal thermal protection.
The body, floor and diffuser of the pump are made from polypropylene reinforced with glass fibre. Its rotor is made from Noryl® reinforced with glass fibres. Supports are made from polyamide reinforced by glass fibre. The motors axis is made from AISI 420. O-rings from NBR. Mechanical seals made from graphite-alumina. L-2521 aluminium motor body. Bobbin impregnated with epoxy varnish.
Dimensions of the pump
Dimensions ESPA SILEN 75 3/4HP model NIMOS 8
![Dimensions pump ESPA Silen 50 1/2HP Dimensions pump ESPA Silen 50 1/2HP](/images/dimensions-pump-espa.jpg)
Dimensions ESPA SILEN 100 1HP model NIMOS 9
![Dimensions ESPA SILEN 100 1HP Dimensions ESPA SILEN 100 1HP](/images/dimensions-espa-silen-100-pump.jpg)
Sand filter
- ASTRAL VESUBIO 500 sand filter
![ASTRAL VESUBIO 450 sand filter ASTRAL VESUBIO 450 sand filter](/images/filter-astral-vesuvio.jpg)
• Filters constructed using the simultaneous projection of glass fibres and resin.
• Equipped with collectors and diffusers made from inalterable PVC.
• Manometer, air and water purge supplied.
• 6-way valve to effectuate filtration, wash, rinse, recirculate, purge and close.
• Maximum working pressure 2kg/cm².
• Service pressure 3kg/cm².
• Equipped with collectors and diffusers made from inalterable PVC.
• Manometer, air and water purge supplied.
• 6-way valve to effectuate filtration, wash, rinse, recirculate, purge and close.
• Maximum working pressure 2kg/cm².
• Service pressure 3kg/cm².
Dimensions of pump
![Dimensions ASTRAL VESUBIO 450 side sand filter Dimensions ASTRAL VESUBIO 450 side sand filter](/images/vesubio-side-sch.jpg)
![Dimensions ASTRAL VESUBIO 450 side sand filter Dimensions ASTRAL VESUBIO 450 side sand filter](/images/vesubio-side-sch.jpg)
![Spacer20 Spacer20](/images/spacer20.jpg)
Diameter filter F (in mm)
500
A (in mm)
305
B (in mm)
125
C (in mm)
765
D (in mm)
400
T (in mm)
200
Connections
1 ½"
Filter recharge (in kg)
95
Included equipment
Skimmer
Discharge nozzles
Main drain
Brush adaptor
Filter
Pump
Maintenance kit includes : Wall brush, telescopic handle, floating pipe, net, analysis pouch, manual vacuum.
Available options:
- Coping
- Choice of colour (using RAL code)
- Thermal cover
- Pool floor projector
- Electrical box
- Salt water treatment
- pH regulation
Standard colour: blue. All other colours are available on option.
Warranty
10 years on watertightness
2 years on other parts
