Material and equipment for your technical shelter Pool filters Oslo sand filter for public pools and large volumes Oslo sand filter for public pools and large volumes
Recommended retail price 2024 starting from :
4443 €
Our Price starting from :
4443 € Including VAT
Ref. Abatik 007537
Ref. Provider 47221
OSLO , Ø1050 , sand filter, filtering speed 30m3/h/m2
Ref. Provider 47221
OSLO , Ø1050 , sand filter, filtering speed 30m3/h/m2
Filters adapted to public pools and pools with large volumes.
Vertically bobbin wound, high-performance,
Filtering height 1200mm
Vertically bobbin wound, high-performance,
Filtering height 1200mm
OSLO Ø1050 sand filter,filtration speed 40m3/h/m2
Ref. Abatik 007538 Ref. Provider 47222
Ref. Abatik 007538 Ref. Provider 47222
4742 €
OSLO , Ø1200 , sand filter, filtration speed 40m3/h/m2
Ref. Abatik 007540 Ref. Provider 47224
Ref. Abatik 007540 Ref. Provider 47224
5662 €
OSLO , Ø1400 sand filter, filtration speed 30m3/h/m2
Ref. Abatik 007541 Ref. Provider 47225
Ref. Abatik 007541 Ref. Provider 47225
6086 €
OSLO , Ø1400 sand filter , filtration speed 40m3/h/m2
Ref. Abatik 007542 Ref. Provider 47226
Ref. Abatik 007542 Ref. Provider 47226
6554 €
OSLO , Ø1600 sand filter, filtration speed 30m3/h/m2
Ref. Abatik 007543 Ref. Provider 47227
Ref. Abatik 007543 Ref. Provider 47227
7464 €
OSLO , Ø1600 sand filter, filtration speed 40m3/h/m2
Ref. Abatik 007544 Ref. Provider 47228
Ref. Abatik 007544 Ref. Provider 47228
7873 €
OSLO , Ø1800 sand filter, filtration speed 30m3/h/m2
Ref. Abatik 007545 Ref. Provider 47229
Ref. Abatik 007545 Ref. Provider 47229
8908 €
OSLO , Ø1800 sand filter, filtration speed 40m3/h/m2
Ref. Abatik 007546 Ref. Provider 47230
Ref. Abatik 007546 Ref. Provider 47230
9621 €
OSLO , Ø2000 sand filter, filtration speed 30m3/h/m2
Ref. Abatik 007547 Ref. Provider 47231
Ref. Abatik 007547 Ref. Provider 47231
10443 €
OSLO , Ø2000 sand filter, filtration speed 40m3/h/m2
Ref. Abatik 007548 Ref. Provider 47232
Ref. Abatik 007548 Ref. Provider 47232
11382 €
OSLO , Ø2350 sand filter, filtration speed 30m3/h/m2
Ref. Abatik 007549 Ref. Provider 47233
Ref. Abatik 007549 Ref. Provider 47233
13200 €
OSLO , Ø2350 sand filter, filtration speed 40m3/h/m2
Ref. Abatik 007550 Ref. Provider 47234
Ref. Abatik 007550 Ref. Provider 47234
14816 €
OSLO , Ø2500 sand filter, filtration speed 30m3/h/m2
Ref. Abatik 007551 Ref. Provider 47217
Ref. Abatik 007551 Ref. Provider 47217
15755 €
OSLO , Ø2500 sand filter, filtration speed 40m3/h/m2
Ref. Abatik 007552 Ref. Provider 47218
Ref. Abatik 007552 Ref. Provider 47218
18866 €
OSLO , Ø3000 sand filter , filtration speed 30m3/h/m2
Ref. Abatik 007553 Ref. Provider 47219
Ref. Abatik 007553 Ref. Provider 47219
26851 €
OSLO , Ø3000 sand filter, filtration speed 40m3/h/m2
Ref. Abatik 007554 Ref. Provider 47220
Ref. Abatik 007554 Ref. Provider 47220
30821 €
OSLO , Ø1050 , sand filter, filtering speed 30m3/h/m2
Ref. Abatik 007537 Ref. Provider 47221
Ref. Abatik 007537 Ref. Provider 47221
4443 €
OSLO , Ø1200 sand filter, filtration speed 30m3/h/m2
Ref. Abatik 007539 Ref. Provider 47223
Ref. Abatik 007539 Ref. Provider 47223
4959 €
The water quality of public pools should be irreproachable. This is why all public pools must reply to the criteria of water quality outlined by heath and safety standards.
Two determinating elements are linked to water quality - filtration and disinfection.
AstralPool Oslo filters for public pools are high performance, vertically bobbin wound. Made from polyester reinforced with glass fiber, totally protected from corrosion, this range of filters proves to be highly resistant mechanically, chemically and thermally.
The principle feature of the Oslo sand filter is the height of the filtering bed. The higher the position of the filtering bed, the higher the filters performance. The excellent performance of the Oslo provides high-quality water.
The Oslo filter's high retaining level contributes to the low level of water turbidity, polluting agents are filtered and therefore, reduced.
Backwash is diminished proportionally to the height of the filtering bed. This results in less water being used, fewer backwash cycles, and less use of the filtrating medium.
The most efficient filtering and backwash use is obtained by an optimised combination of the filtering medium - this is ideally composed of anthracite, sand and gravel, recommended for filtering beds of 1.20m and more, reducing friction loss and increasing filtering power.
Filtration height 1.20m.
Iso neopentyl-glycol protective gel coat type CSS-UP3 is used for manufacture. Rigid and resistant to sand abrasion and salt water • Replies to the KTW recommendation and is certified LVHT • The ozone resistant option has a vinylester protective layer, type CSS-PHA5. • Laminated with non-orientated glass fiber reinforced polyester, type GF-UP1 • Reinforced in the zones where type MW piercings are present, alternated with layers of alternated fibers and non-alternated fibers. • Bobbin wound with radial layers on the cylindrical section and GF-UP1 type polar layers the length of the filter. Digitally controlled bobbin manufacturing process. • High-performance mechanical resistance to internal pressure • Outer protective layer of de polyurethane resistant to U.V. • All these of filters have been submitted to a 60ºC hardening process.
Two determinating elements are linked to water quality - filtration and disinfection.
Astral OSLO filters
AstralPool Oslo filters for public pools are high performance, vertically bobbin wound. Made from polyester reinforced with glass fiber, totally protected from corrosion, this range of filters proves to be highly resistant mechanically, chemically and thermally.
The principle feature of the Oslo sand filter is the height of the filtering bed. The higher the position of the filtering bed, the higher the filters performance. The excellent performance of the Oslo provides high-quality water.
The Oslo filter's high retaining level contributes to the low level of water turbidity, polluting agents are filtered and therefore, reduced.
Backwash is diminished proportionally to the height of the filtering bed. This results in less water being used, fewer backwash cycles, and less use of the filtrating medium.
The most efficient filtering and backwash use is obtained by an optimised combination of the filtering medium - this is ideally composed of anthracite, sand and gravel, recommended for filtering beds of 1.20m and more, reducing friction loss and increasing filtering power.
Features of the Oslo filter
1. Ø 400mm recharge access
2. Air purge
3. PVC pipework
4. Optional level indicator
5. Ø 400mm lateral access orifice (optional)
6. PP sieved floor
7. Air wash connection
8. Polyester supporting base
2. Air purge
3. PVC pipework
4. Optional level indicator
5. Ø 400mm lateral access orifice (optional)
6. PP sieved floor
7. Air wash connection
8. Polyester supporting base
Level indicator
This allows regular inspection of the filters sand level and verifies the expansion of the sandbed during the wash cycle. This can be positioned in several areas of the filter tank.
This allows regular inspection of the filters sand level and verifies the expansion of the sandbed during the wash cycle. This can be positioned in several areas of the filter tank.
lateral access oriphice
To incorporate the filtering recharge and facilitate access to the filter - can be positioned in several areas of the filter tank
To incorporate the filtering recharge and facilitate access to the filter - can be positioned in several areas of the filter tank
Sieved floor
System with sieved floor with 0,5 mm grooves for air wash, lessening water consumption reducing costs and contributing to water preservation. This also contributes to the evacuation of stagnant water present in conventional models with tubed collectors
System with sieved floor with 0,5 mm grooves for air wash, lessening water consumption reducing costs and contributing to water preservation. This also contributes to the evacuation of stagnant water present in conventional models with tubed collectors
Collector
Tubed collector system with grooves 0,3 mm evenly distributing for perfect water circulation.
Tubed collector system with grooves 0,3 mm evenly distributing for perfect water circulation.
Dimensions of Oslo filter
Collectors tubes
Sieved floor
Filtration height 1.20m.
Technical features
- Maximum operational temperature 50ºC.
- Conform to EU regulation relating to pressure 97/23/CE, paragraph 3, article 3.
- Hydraulic pressure tested
1,5 x maximum entry pressure.
- Resistance and thickness calculations are based on the norm BS-4994 and AD-Merkblatt N1.
- PVC internal components and pipework.
- PP sieves.
- Lower connection for air washes on models with a sieved floor.
- AISI-316 stainless steel hardware.
- EPDM O-rings.
- Varied positions for level sight glass and openings
- Varied diameters for connections and purge valves .
- Maximum operational temperature 50ºC.
- Conform to EU regulation relating to pressure 97/23/CE, paragraph 3, article 3.
- Hydraulic pressure tested
1,5 x maximum entry pressure.
- Resistance and thickness calculations are based on the norm BS-4994 and AD-Merkblatt N1.
- PVC internal components and pipework.
- PP sieves.
- Lower connection for air washes on models with a sieved floor.
- AISI-316 stainless steel hardware.
- EPDM O-rings.
- Varied positions for level sight glass and openings
- Varied diameters for connections and purge valves .
Specifications/equipment
- 400mm access orifice
- Upper air purge connection
- Tubed, grooved collector 0.3mm
- Working pressure 2.5 bars to 4 bars
- Lower water purge
- Filter bed height 1200mm
- Pressure gauge
- 400mm access orifice
- Upper air purge connection
- Tubed, grooved collector 0.3mm
- Working pressure 2.5 bars to 4 bars
- Lower water purge
- Filter bed height 1200mm
- Pressure gauge
Material used for the manufacture of DIN 18820:
Iso neopentyl-glycol protective gel coat type CSS-UP3 is used for manufacture. Rigid and resistant to sand abrasion and salt water • Replies to the KTW recommendation and is certified LVHT • The ozone resistant option has a vinylester protective layer, type CSS-PHA5. • Laminated with non-orientated glass fiber reinforced polyester, type GF-UP1 • Reinforced in the zones where type MW piercings are present, alternated with layers of alternated fibers and non-alternated fibers. • Bobbin wound with radial layers on the cylindrical section and GF-UP1 type polar layers the length of the filter. Digitally controlled bobbin manufacturing process. • High-performance mechanical resistance to internal pressure • Outer protective layer of de polyurethane resistant to U.V. • All these of filters have been submitted to a 60ºC hardening process.
Recommended filter recharges
