Eolia WEX100 bulb

Eolia WEX100 bulb for pool projector
Recommended retail price 2024 :
672 €
Our Price :
672 € Including VAT
Ref. Abatik 014495
Ref. Provider PF10R005
Eolia WEX100 bulb
EUR 672.00
9 LED pool projector bulb
Easy installation in standard PAR56 alcoves
Powerful 3000lm beam
Low energy consumption
Multicoloured light
In stock
The Eolia WEX100 bulb for pool projectors creates various atmospheres for your pool by means of the featured multicoloured LEDs.

Easy to install, this bulb fits standard PAR-56 alcoves. Its dimensions replace perfectly a 300w 12v classic filament bulb without further modification.
Using LED technology, this bulb benefits from a superior lifespan in comparison to a classic bulb, reducing by nearly 80% energy consumption.

Technical details

The outer casing of this bulb is made from aluminium, favouring heat dispersion.
Its glass focus ensures better resistance to corrosion and chemical products.

Perfectly adapted to prolonged immersion, the various connections of the bulb are made from 316L stainless steel and feature a 9 point sealing flange.

The colours projected are obtained by mixing 3 primary colours (red, green and blue) and are adjusted by the white LEDs. The adjustment of these 4 luminous sources allows the obtention of nearly 4 million shades of colour.

Operational modes

Available colours Eolia WEX100 bulb for pool projector

The Eolia WEX100 operates independently and features 7 predefined lighting sequences that you can selection by the simple press of a button : static, sequenced or merged.
You can equally choose from 7 static colours and an automatic sequence of varied colour.

Distance control is also possible by using the radio remote control connected to a command box (available on option).
LED shades

Installing the bulb

The pool bulb (2) can be installed in all standard PAR-56 alcoves (1) replacing a filament bulb. Connection is easy and water tightness is guaranteed. Aluminium outer casing evacuates heat and adds to the long lifespan of the LEDs
Low energy consumption (60w max) allows intensive use without risk of the transformer overheating, resolving the problems linked to voltage drops.

Installation schema

Transformer capacity

To operate, the Eolia WEX100 must be connected to a transformer with a secondary output of 12v.

The power provided must be adequate to power the total number of LED bulbs connected. The sum of the power produced by the bulbs must always be equal or lesser than the transformer.

For example, a 300VA transformer can power up to 3 Eolia WEX100 bulbs.

When connecting, an individual protection must be provided for each projector by using an 8A trip switch or fuse.

Violet light in situ

Technical characteristics

Power supply
12V AC 50Hz/60Hz
Consumed power
Type of LED
Number of LEDs
Number of colours
4 million
Colour control
On/off switch or distance control with radio remote control with Brio box (on option
Weight of bulb
Packed weight of bulb
Protection index

Contents of packaging

- 1 Eolia WEX100 bulb
- 2 stainless steel screws and washers for fixation
- 1 instruction sheet


2 years
